Introduction
Steel plate strip is a flat and narrow steel product cut from steel plates or coils produced by hot rolling or cold rolling processes. It is widely used in manufacturing, construction, automotive parts, machinery, and metal fabrication.
| Tolerance | ±1% |
| type | Hot rolled carbon steel coil |
| Thickness | 0.05-2mm or as required |
| Width | 3mm-300m or as required |
| Length | Size can be Customized |
| Surface | Bare,Black,Oiled,Shot Blasted, Spray Paint,Coated,Galvanized,or as Your Request |
| Material | Q195, Q215,Q235,Q345,ST37, A36,45# ,16Mn, SPHC,SGCC,CGCC |
| Application | Construction, machinery manufacturing, container manufacturing, shipbuilding, bridges, etc. |
Material and Chemical Composition
The material of the steel strips is mainly carbon structural steel and low-alloy high-strength structural steel. In some scenarios, special materials such as stainless steel and heat-resistant steel will be used. The chemical composition of different grades strictly follows the corresponding standards. The core components and characteristics are as follows:
| Material Grade | C | Si | Mn | P | S |
| Q235 | ≤0.22 | ≤0.35 | ≤1.40 | ≤0.045 | ≤0.050 |
| Q355 | ≤0.20 | ≤0.55 | ≤1.60 | ≤0.035 | ≤0.035 |
| Q460 | ≤0.20 | ≤0.60 | ≤1.80 | ≤0.035 | ≤0.035 |
Mechanical Properties
The mechanical properties of the steel strip are determined by the material, processing method (hot rolling / cold rolling), and heat treatment method. The key indicators and general application scope are as follows:
| Performance Metrics | Q235B | S235JR | A36 | SS400 |
| Yield Strength(ReL) | ≥ 235 MPa | ≥ 235 MPa | ≥ 250 MPa | ≥ 245 MPa |
| Tensile Strength(Rm) | 370 - 500 MPa | 360 - 510 MPa | 400 - 550 MPa | 400 - 510 MPa |
| Elongation(A) | ≥ 26% | ≥ 26% | ≥ 20% | ≥ 21% |
| HB(HB) | ≈ 120 - 150 | ≈ 120 - 150 | ≈ 120 - 150 | ≈ 120 - 150 |
| Impact Work (Akv) | ≥ 27 J (20℃) | ≥ 27 J (20℃) | ≥ 27 J (20℃) | ≥ 27 J (20℃) |
Features
- Precise Width and Thickness
Steel plate strips are produced through precision slitting processes, ensuring its accurate width and consistent thickness.
- Strict Quality Control
Made from high-quality steel materials which are produced under strict quality control procedures, ensuring consistent performance and compliance with industry standards.
- Good Processing Performance
Steel plate strips are easy to cut, bend, stamp, and weld, allowing manufacturers to efficiently process them into various components and parts.
Custom Services
- Custom Sizes
Width, thickness, and length can be produced according to customer specifications.
- Surface Treatment
Options include galvanized, pickled, oiled, coated, or polished surfaces.
- Material Grade Selection
Various steel grades available based on strength and application requirements.
FAQs
- What is the typical width range of steel plate strips?
The width of steel plate strips can vary depending on the production process, but they are generally narrower than standard steel plates and can be slit to meet specific application requirements.
- Can steel plate strips be further processed after purchase?
Yes, steel plate strips can be further processed through bending, stamping, welding, or forming to produce different components and structural parts.
- How are steel plate strips typically stored?
They should be stored in a dry and well-ventilated environment to prevent moisture exposure and maintain surface quality.
